To design a logic circuit that adds two 4-bit binary numbers, taking into account the carry-over from the addition, and outputs the result as a 4-bit binary number along with a single bit indicating if there was an overflow, we can follow these steps:
1. **Define the Inputs and Outputs:**
- Inputs: Two 4-bit binary numbers ( A_3A_2A_1A_0 ) and ( B_3B_2B_1B_0 ), and an initial carry ( C_{in} ) (which is 0 if not previously generated by another adder).
- Outputs: A 4-bit binary sum ( S_3S_2S_1S_0 ) and an overflow bit ( C_{out} ).
2. **Parallel Adder for 4 Bits:**
Each bit of the sum can be calculated using a full adder. A full adder takes three inputs: two bits to be added plus a carry-in, and produces a sum bit and a carry-out.
For simplicity, we will use half adders and full adders for each bit position, where a half adder can be used for the least significant bit (LSB).
3. **Logic for Each Bit:**
- **Least Significant Bit (4th bit or ( A_0 + B_0 + C_{in} )):**
- Use a half adder for ( A_0 + B_0 ) and an OR gate to generate ( C_{in} ) for the next bit.
- Sum for ( A_0 + B_0 ): ( S_0 = A_0 oplus B_0 )
- Carry for ( A_0 + B_0 ): ( C_1 = A_0 cdot B_0 )
- **Second Bit (3rd bit or ( A_1 + B_1 + C_1 )):**
- Use a full adder for ( A_1 + B_1 + C_1 ).
- Sum for ( A_1 + B_1 + C_1 ): ( S_1 = (A_1 oplus B_1) oplus C_1 )
- Carry for ( A_1 + B_1 + C_1 ): ( C_2 = (A_1 cdot B_1) lor (C_1 cdot (A_1 oplus B_1)) )
- **Third Bit (2nd bit or ( A_2 + B_2 + C_2 )):**
- Use a full adder for ( A_2 + B_2 + C_2 ).
- Sum for ( A_2 + B_2 + C_2 ): ( S_2 = (A_2 oplus B_2) oplus C_2 )
- Carry for ( A_2 + B_2 + C_2 ): ( C_3 = (A_2 cdot B_2) lor (C_2 cdot (A_2 oplus B_2)) )
- **Most Significant Bit (1st bit or ( A_3 + B_3 + C_3 )):**
- Use a full adder for ( A_3 + B_3 + C_3 ).
- Sum for ( A_3 + B_3 + C_3 ): ( S_3 = (A_3 oplus B_3) oplus C_3 )
- Carry for ( A_3 + B_3 + C_3 ): ( C_4 = (A_3 cdot B_3) lor (C_3 cdot (A_3 oplus B_3)) )
4. **Overflow Bit Calculation:**
- An overflow occurs in 4-bit addition if the carry into the 5th bit ( C_4 ) is generated, which means ( C_{out} = C_4 ).
5. **Summary of Circuit:**
- The 4-bit adder with an overflow bit involves 4 full adders for the 4 bits and a series of AND and OR gates for the carry propagation.
- The final carry out ( C_{out} ) is derived directly from the carry into the 5th bit.
By following these steps, the circuit will correctly add two 4-bit binary numbers and indicate an overflow if one occurs. The final output is 4 bits for the sum and 1 bit for the overflow.
[
